PERFORMANCE DATA (CONT.)
INSTANTANEOUS AND INTEGRATED HEATING RATINGS
38MVQ012--3 / 40MVQ012--3
Air Temperature
Entering Indoor
Unit _F(_C)
Indoor
Airflow
(CFM)
L --- M --- H
Item
Air Temperature Entering Outdoor Coil --- DB/WB _F(_C)
57/53 (13.89/11.67) 47/43 (8.33/6.11) 37/33 (2.78/0.56) 27/23 (---2.78/---5) 17/13 (---8.33/---10.56)
Instant. Integrated Instant. Integrated Instant. Integrated Instant. Integrated Instant. Integrated
Rating Rating Rating Rating Rating Rating Rating Rating Rating Rating
55 (12.78)
304
Cap 15.21 15.21 13.32 13.32 11.58 10.54 9.83 8.73 8.06 7.35
kW 1.08 0.99 0.91 0.84 0.77
343
Cap 15.31 15.31 13.40 13.40 11.75 10.69 9.94 8.83 8.20 7.48
kW 1.02 0.94 0.88 0.81 0.76
414
Cap 15.37 15.37 13.47 13.47 11.84 10.78 10.10 8.97 8.44 7.69
kW 0.95 0.89 0.83 0.78 0.73
60 (15.56)
304
Cap 15.01 15.01 13.16 13.16 11.37 10.35 9.64 8.56 7.81 7.12
kW 1.13 1.04 0.95 0.88 0.81
343
Cap 15.13 15.13 13.25 13.25 11.54 10.50 9.76 8.67 7.94 7.24
kW 1.08 0.99 0.92 0.85 0.79
414
Cap 15.23 15.23 13.33 13.33 11.71 10.65 9.92 8.81 8.12 7.40
kW 1.01 0.93 0.88 0.82 0.77
65 (18.33)
304
Cap 14.80 14.80 12.96 12.96 11.18 10.17 9.43 8.37 7.55 6.89
kW 1.18 1.09 1.00 0.92 0.84
343
Cap 14.94 14.94 13.08 13.08 11.33 10.31 9.56 8.49 7.69 7.01
kW 1.13 1.04 0.97 0.89 0.82
414
Cap 15.06 15.06 13.16 13.16 11.55 10.51 9.74 8.65 7.86 7.17
kW 1.06 0.98 0.93 0.86 0.80
70 (21.11)
304
Cap 14.58 14.58 12.77 12.77 10.97 9.99 9.10 8.08 7.28 6.64
kW 1.24 1.14 1.04 0.95 0.87
343
Cap 14.74 14.74 12.89 12.89 11.12 10.12 9.28 8.24 7.42 6.76
kW 1.19 1.09 1.01 0.93 0.86
414
Cap 14.90 14.90 13.01 13.01 11.33 10.31 9.53 8.46 7.61 6.94
kW 1.11 1.03 0.97 0.90 0.83
75 (23.89)
304
Cap 14.35 8.66 12.57 12.57 10.76 8.66 8.83 7.84 7.04 6.42
kW 1.30 1.19 1.09 0.98 0.91
343
Cap 14.51 8.89 12.70 12.70 10.92 8.89 8.98 7.97 7.15 6.52
kW 1.24 1.15 1.06 0.96 0.89
414
Cap 14.69 14.69 12.84 12.84 11.12 10.12 9.21 8.18 7.32 6.68
kW 1.17 1.09 1.02 0.93 0.87
80 (26.67)
304
Cap 14.12 14.12 12.32 12.32 10.52 9.57 8.56 7.60 6.80 6.20
kW 1.35 1.24 1.13 1.02 0.95
343
Cap 14.29 14.29 12.51 12.51 10.69 9.73 8.70 7.72 6.92 6.31
kW 1.30 1.20 1.10 1.00 0.93
414
Cap 14.48 14.48 12.65 12.65 10.91 9.93 8.92 7.92 7.06 1.41
kW 1.22 1.14 1.06 0.97 0.91
Indicates Rating Condition (* Integrated Capacity) Indicates Integrated Rating
Cap --- Heating Capacity (100 Btuh), Includes indoor f an motor heat
kW --- Total Power Input, includes compressor motor power input, outdoor fan motor power input, and indoor fan motor power input
Note: Integrated Capacity is maximum (instantaneous ) capacity less the effect of frost on the outdoor coil and the heat to defrost it.
38/40MVC, MVQ
