Carrier 40MVC User Manual

8
PHYSICAL DATA (CONT.)
Indoor Unit 40MVC 009 012 018 024
System Voltage 115 115 or 208/230 208/230 208/230
Nominal Capacity (Btuh) 9000 12000 18000 24,000
Operating Weight lb(kg) 17.6(8) 25.3(11.5) 39.6(18) 39.6(18)
Refrigerant Type R---410A
Metering Device Capillary Tube at Outdoor
Charge (lb) 2.3(1.0) 2.9(1.3) 4.4(2.0) 5.3(2.4)
Indoor Fan
Rpm/Cfm (High) 1250/325 1270/425 1070/630 1070/750
Rpm/Cfm (Medium) 1000/260 1100/365 1000/570 1000/660
Rpm/Cfm (Low) 800/ 190 1000/340 960/500 960/585
Motor (Watts / hp) 20 / .034 25 / .044 31 / .075 50 / .112
Blower D iameter … Length (in) 3.84 … 25.87 4.17 … 25.2 4.21 … 37.6 4.21 … 37.6
Indoor Coil
Face Area (sq. ft) 2.15 2.54 4.36 4.36
No. Rows 2 2 2 2
Fins per inch 19.5 19.5 19.5 19.5
Circuits 2 3 6 6
Controls Integrated Microprocessor
Remote Controller Wireless
Fan Mode High/Medium/Low/Auto
Turbo Mode Ye s Yes No No
Dehumidification Mode Ye s
Sleep Mode Ye s
Diagnostics Ye s
Timer Mode Ye s
Freeze Protection Ye s
Test Mode Ye s
Auto Restart Yes
Auto Sweep Ye s
Control Voltage 13 VDC 13 VDC Pulse DC Pulse DC
Refrigerant Lines
Connection Type Flare
Liquid Line (in) OD 1/4” 1/4” 1/4” 3/8”
Vapor Line (in) OD 3/8” 1/2” 1/2” 5/8”
Maximum Length ft(m)* 65(19.8) 65(19.8) 100(30.5) 100(30.5)
Max Lift (Fan Coil Above) ft(m) 35(10.7) 35(10.7) 50(15.2) 60(18.3)
Max D r op (Fan Coil Below) ft(m) 35(10.7) 35(10.7) 50(15.2) 60(18.3)
Condensate Drain
Size (in) .65 (OD) .53 (ID) .65 (OD) .53 (ID) .65 (OD) .53 (ID) .65 (OD) .53 (ID)
External Finish White White White White
* Refer to Long Line Application section on page 21
