8
OUTDOOR UNIT DIMENSIONS
H
G
L
A
B
1"
8"
4 1/2"
1 7/16"
UNIT SERIES
ELECTRICAL
CHARACTERISTICS
AB C D E F G H J KLMNP
OPERATING
WEIGHT(lbs)
SHIPPING
WEIGHT(lbs)
SHIPPING
DIMENSIONS (L x W x H)
38HDR018 1 X O O O 25 1/8" 36 15/16" 14 9/16" 16" 23 7/16" 17 3/16" 17 1/8" 22" 13" 6 5/8" 11 1/4" 5/8" 2 15/16" 6" 155 171 42 9/10" X 18" X 28 1/10"
38HDR024 1,2 X O O O 31 1/8" 36 15/16" 14 9/16" 16" 23 7/16" 17 3/16" 23 1/8" 28" 14" 6 3/4" 11 5/8" 5/8" 2 15/16" 6" 180 198 42 9/10" X 18" X 34 1/10"
38HDR030 1 X O O O 37 3/16" 44 9/16" 17 1/16" 18 7/16" 30 1/2" 19 5/8" 29 3/16" 34 1/16" 13 11/16" 8 1/8" 15 7/8" 3/4" 3 7/16" 6 1/2" 200 223 50 1/2" X 20 1/2" X 40 2/10"
38HDR036 1 X O X X 37 3/16" 44 9/16" 17 1/16" 18 7/16" 30 1/2" 19 5/8" 29 3/16" 34 1/16" 13 11/16" 8 1/8" 15 7/8" 3/4" 3 7/16" 6 1/2" 218 240 50 1/2" X 20 1/2" X 40 2/10"
38HDR048 1,2 X O X X 43 3/16" 44 9/16" 17 1/16" 18 7/16" 30 1/2" 19 5/8" 35 3/16" 40 1/16" 14 1/2" 8 1/2" 18 7/8" 7/8" 3 7/16" 6 1/2" 284 309 50 1/2" X 20 1/2" X 46 2/10"
38HDR060 1,2 X O X X 43 3/16" 44 9/16" 17 1/16" 18 7/16" 30 1/2" 19 5/8" 35 3/16" 40 1/16" 14 1/2" 8 1/2" 18 7/8" 7/8" 3 7/16" 6 1/2" 294 319 50 1/2" X 20 1/2" X 46 2/10"
UNIT SIZE
MINIMUM
MOUNTING PAD
DIMENSIONS
18,24 23" X 42"
30,36,48,60 24" X 50"
208-230-1-60
230-1-60
208/230-3-60
460-3-60
1 1/2"
FIELD CONTROL SUPPLY
WIRE ENTRY
7/8" HOLE W/GROMMET
1. REQUIRED CLEARANCES: WITH COIL FACING WALL; ALLOW 6" MIN
CLEARANCE ON COIL SIDE AND COIL END AND 36" MIN CLEARANCE
ON COMPRESSOR END AND FAN SIDE. WITH FAN FACING WALL; ALLOW 8" MIN
CLEARANCE ON FAN SIDE AND COIL END AND 36" MIN CLEARANCE
ON COMPRESSOR END AND COIL SIDE. WITH MULTI UNIT APPLICATION;
ARRANGE UNITS SO DISCHARGE OF ONE DOES NOT ENTER INLET OF ANOTHER.
2. MINIMUM OUTDOOR OPERATING AMBIENT IN COOLING
MODE IS 55
F, MAX. 125 F.
3. SERIES DESIGNATION IS THE 13TH POSITION OF THE
UNIT MODEL NUMBER.
4. CENTER OF GRAVITY
5. ALL DIMENSIONS ARE IN "INCHES" UNLESS NOTED.
FIELD POWER SUPPLY CONN.
HOLE SIZES PROVIDED:
7/8"-1/2"TRADE
1 3/16"-3/4"TRADE
1 3/8"-1"TRADE
3/8" LIQUID LINE
FEMALE SWEAT CONN.
X = YES
O = NO
FEMALE SWEAT CONN.
VAPOR LINE CONN.
M
JUNCTION BOX FOR
POWER SUPLLY AND
CONTROL CONNECTIONS
4 3/16"
J
N
P
E
FD
7 1/2"
2 1/2"
11/16"
C
K
N
AIR
AIR
Fig. 5 – 38HDR Dimensions -- English
40QAC/38HDR -- 40QAQ/38QRR
