Table 3 — High Wall Unit Package Contents
ITEM QUANTITY
Unit Mounting Template 1
Unit Mounting Bracket 1
1-in. Lag Screws For Unit Mounting 8
Hollow Wall Anchor Bolts For Unit Mounting 5
Wall Sleeve With Wall Cap 1
Infrared Wireless Remote Control Assembly 1
AAA Batteries (For Remote Control) 2
Remote Control Mounting Bracket 1
3
⁄
8
-in. Lag Screws For Remote Mounting Bracket 2
35 ft Long High Voltage Power Wiring (2-wire with ground) 1
35 ft Long Low Voltage Thermistor Wiring (3-wire) 1
AccuRaterT Body And Piston (018 and 024 Cooling Only Units)* 1
Biflow Filter Drier 1
Owner’s Manual 1
Installation Instructions 1
Warranty Registration Card 1
*For heat pumps: additional heating AccuRater body and piston shipped with outdoor unit.
*A clearance of 49 is the absolute minimum. A clearance of 109 is
recommended.
NOTE: Remove unit front cover for control box access.
Fig. 3 — Minimum Required Clearances
4
