Carrier 40VMW005 - Page 4

4
NOTE: All dimensions shown in inches.
Fig. 2 —40VMW005-018 Dimensions
Fig. 3 —40VMW024, 030 Dimensions
40VMW UNIT SIZE
DIMENSION
A B C D
005-012 36 11
3
/
8
9 28
3
/
4
015-018 42
1
/
4
12
3
/
8
9 35
1
/
8
40VMW UNIT SIZE
DIMENSION
A B C D
024, 030 47 13
1
/
2
10
1
/
8
42
3
/
8
C
D
A
B
D
A
B
C
