45MBDAQ: Installation Instructions
Manufacturer reserves the right to change, at any time, specifications and designs without notice and without obligations.
4
Table 2 — A (min)
For R454B refrigerant charge amount and minimum room area:
The indoor unit should be installed at least 5.9ft/1.8m above the floor, and the minimum room area for operation or storage should be as
specified in Table 2.
NOTE: For units installed in the conditioned space, users may need to adjust temperatures compensations for sensed space temperature.
Configuration found in IR remote manual for parameter setting.
Ho, release height ft (m)
MC or Mrel
Refrigerant Charge Amount
pounds (kilograms)
Mc or Mrel (lbs(kgs) ≤ 7.2 (2.2) 7.5 (2.3) 7.9 (2.4) 8.5 (2.6) 9.2 (2.8) 9.8 (3.0)
≤ 3.91 (1.776) 12 (1.10)
4.0 (1.8)
60 (5.53) 57 (5.29) 55 (5.07) 50 (4.68) 47 (4.34) 44 (4.05)
4.4 (2.0)
66 (6.14) 63 (5.88) 61 (5.63) 56 (5.2) 52 (4.83) 48 (4.5)
4.9 (2.2)
73 (6.76) 70 (6.46) 67 (6.19) 62 (5.72) 57 (5.31) 53 (4.95)
5.3 (2.4)
79 (7.37) 76 (7.05) 73 (6.76) 67 (6.24) 62 (5.79) 58 (5.41)
5.7 (2.6)
86 (7.99) 82 (7.64) 79 (7.32) 73 (6.76) 68 (6.27) 63 (5.86)
6.2 (2.8)
93 (8.6) 89 (8.23) 85 (7.88) 78 (7.28) 73 (6.76) 68 (6.31)
6.6 (3.0)
99 (9.21) 95 (8.81) 91 (8.45) 84 (7.8) 78 (7.24) 73 (6.76)
7.1 (3.2)
106 (9.83) 101 (9.4) 97 (9.01) 90 (8.32) 83 (7.72) 78 (7.21)
7.5 (3.4)
112 (10.44) 108 (9.99) 103 (9.57) 95 (8.84) 88 (8.2) 82 (7.66)
7.9 (3.6)
119 (11.06) 114 (10.58) 109 (10.14) 101 (9.36) 94 (8.69) 87 (8.11)
8.4 (3.8)
126 (11.67) 120 (11.16) 115 (10.7) 106 (9.88) 99 (9.17) 92 (8.56)
8.8 (4.0)
132 (12.29) 126 (11.75) 121 (11.26) 112 (10.4) 104 (9.65) 97 (9.01)
9.3 (4.2)
139 (12.9) 133 (12.34) 127 (11.82) 117 (10.91) 109 (10.14) 102 (9.46)
9.7 (4.4)
145 (13.51) 139 (12.93) 133 (12.39) 123 (11.43) 114 (10.62) 107 (9.91)
10.1 (4.6)
152 (14.13) 145 (13.51) 139 (12.95) 129 (11.95) 119 (11.1) 112 (10.36)
10.6 (4.8)
159 (14.74) 152 (14.1) 145 (13.51) 134 (12.47) 125 (11.58) 116 (10.81)
11 (5.0)
165 (15.36) 158 (14.69) 152 (14.08) 140 (12.99) 130 (12.07) 121 (11.26)
11.5 (5.2)
172 (15.97) 164 (15.28) 158 (14.64) 145 (13.51) 135 (12.55) 126 (11.71)
11.9 (5.4)
179 (16.58) 171 (15.86) 164 (15.2) 151 (14.03) 140 (13.03) 131 (12.16)
12.3 (5.6)
185 (17.2) 177 (16.45) 170 (15.77) 157 (14.55) 145 (13.51) 136 (12.61)
12.8 (5.8)
192 (17.81) 183 (17.04) 176 (16.33) 162 (15.07) 151 (14) 141 (13.06)
13.2 (6.0)
198 (18.43) 190 (17.63) 182 (16.89) 168 (15.59) 156 (14.48) 145 (13.51)
13.7 (6.2)
205 (19.04) 196 (18.21) 188 (17.45) 173 (16.11) 161 (14.96) 150 (13.96)
14.1 (6.4)
212 (19.66) 202 (18.8) 194 (18.02) 179 (16.63) 166 (15.44) 155 (14.41)
14.6 (6.6)
218 (20.27) 209 (19.39) 200 (18.58) 185 (17.15) 171 (15.93) 160 (14.86)
15 (6.8)
225 (20.88) 215 (19.98) 206 (19.14) 190 (17.67) 177 (16.41) 165 (15.32)
15.4 (7.0)
231 (21.5) 221 (20.56) 212 (19.71) 196 (18.19) 182 (16.89) 170 (15.77)
15.9 (7.2)
238 (22.11) 228 (21.15) 218 (20.27) 201 (18.71) 187 (17.37) 175 (16.22)
Amin ( ft2 (m2)
Mc - Actual refrigerant charge in the system lbs (Kg)
Mrel - Refrigerant releasable charge lbs (kg)
Ho - Release height, measured from duct opening, in ft (m)
Hinst - Height of install, from the bottom of the indoor appliance, measured in ft (m)
Ho ≈ Hinst
Warning: Minimum room area of conditioned space is based on releasable charge or total system refrigerant charge.
To Next Page
