124
APPENDIX A — LOCAL DISPLAY TABLES (cont)
MODE — RUN STATUS (cont)
MODE — SERVICE TEST
MODE — TEMPERATURES
ITEM EXPANSION RANGE UNITS CCN POINT WRITE STATUS PAGE NO.
TMGD TIMEGUARDS
→ TG.A1 Compressor A1 Timeguard CMPA1_TG 86
→ TG.A2 Compressor A2 Timeguard CMPA2_TG 86
→ TG.B1 Compressor B1 Timeguard CMPB1_TG 86
→ TG.B2 Compressor B2 Timeguard CMPB2_TG 86
→ TG.H1 Heat Relay 1 Timeguard HS1_TG 86
→ TG.H2 Heat Relay 2 Timeguard HS2_TG 86
→ TG.H3 Heat Relay 3 Timeguard HS3_TG 86
→ TG.H4 Heat Relay 4 Timeguard HS4_TG 86
→ TG.H5 Heat Relay 5 Timeguard HS5_TG 86
→ TG.H6 Heat Relay 6 Timeguard HS6_TG 86
VERS SOFTWARE VERSION NUMBERS
→ MBB CESR131343-xx-xx string 86
→ ECB1 CESR131249-xx-xx string 86
→ ECB2 CESR131249-xx-xx string 86
→ SCB CESR131226-xx-xx string 86
→ CEM CESR131174-xx-xx string 86
→ MARQ CESR131171-xx-xx string 86
→ NAVI CESR130227-xx-xx string 86
ITEM EXPANSION RANGE UNITS CCN POINT WRITE STATUS PAGE NO.
TEST Service Test Mode ON/OFF MAN_CTRL
STOP Local Machine Disable YES/NO UNITSTOP config 29
S.STP Soft Stop Request YES/NO SOFTSTOP forcible 29
FAN.F Supply Fan Request YES/NO SFANFORC forcible 29
F.4. CH 4 in. Filter Change Mode YES/NO FILT4CHG 29
INDP TEST INDEPENDENT OUTPUTS
→ ECN.C Economizer Act.Cmd.Pos. ECONCTST 30
→ E.PWR Economizer Power Test ECONPTST 30
→ E.CAL Calibrate the Economizer? ECON_CAL 30
→ PE.A Power Exhaust Relay A PE_A_TST 30
→ PE.B Power Exhaust Relay B PE_B_TST 30
→ PE.C Power Exhaust Relay C PE_C_TST 30
→ H.I.R Heat Interlock Relay ON/OFF HIR_TST 30
→ ALRM Remote Alarm/Aux Relay ON/OFF ALRM_TST 30
FANS TEST FANS
→ S.FAN Supply Fan Relay ON/OFF SFAN_TST 30
→ S.VFD Supply Fan VFD Speed 0-100 % SGVFDTST 30
→ CD.F.A Condenser Fan Circuit A ON/OFF CNDA_TST 30
→ CD.F.B Condenser Fan Circuit B ON/OFF CNDB_TST 30
COOL TEST COOLING
→ A1 Compressor A1 Relay ON/OFF CMPA1TST 30
→ A2 Compressor A2 Relay ON/OFF CMPA2TST 30
→ MLV Min. Load Valve (HGBP) ON/OFF MLV_TST 30
→ B1 Compressor B1 Relay ON/OFF CMPB1TST 30
→ B2 Compressor B2 Relay ON/OFF CMPB2TST 30
HEAT TEST HEATING
→ HT.ST Requested Heat Stage 0-MAX HTST_TST 30
→ HT.1 Heat Relay 1 ON/OFF HS1_TST 30
→ HT.2 Heat Relay 2 ON/OFF HS2_TST 30
→ HT.3 Relay 3 W1 Gas Valve 2 ON/OFF HS3_TST 30
→ HT.4 Relay 4 W2 Gas Valve 2 ON/OFF HS4_TST 30
→ HT.5 Relay 5 W1 Gas Valve 3 ON/OFF HS5_TST 30
→ HT.6 Relay 6 W2 Gas Valve 3 ON/OFF HS6_TST 30
ITEM EXPANSION RANGE UNITS CCN POINT WRITE STATUS
AIR.T AIR TEMPERATURES
→ CTRL CONTROL TEMPS
→ CTRL → EDT Evaporator Discharge Tmp dF EDT
→ CTRL → LAT Leaving Air Temperature dF LAT
→ CTRL → MAT Mixed Air Temperature dF MAT
→ CTRL → R.TMP Controlling Return Temp df RETURN_T forcible
→ CTRL → S.TMP Controlling Space Temp df SPACE_T forcible
→ SAT Air Tmp Lvg Supply Fan dF SAT
→ OAT Outside Air Temperature –40 - 240 dF OAT forcible
→ RAT Return Air Temperature dF RAT forcible
→ SPT Space Temperature –40 - 240 dF SPT forcible
→ SPTO Space Temperature Offset ^F SPTO forcible
→ S.G.LS Staged Gas LAT Sum dF LAT_SGAS
→ S.G.L1 Staged Gas LAT 1 dF LAT1SGAS
→ S.G.L2 Staged Gas LAT 2 dF LAT2SGAS
→ S.G.L3 Staged Gas LAT 3 dF LAT3SGAS
→ S.G.LM Staged Gas Limit Sw.Temp dF LIMSWTMP
REF.T REFRIGERANT TEMPERATURES
→ SCT.A Cir A Sat.Condensing Tmp dF SCTA
→ SST.A Cir A Sat.Suction Temp. dF SSTA
→ SCT.B Cir B Sat.Condensing Tmp dF SCTB
→ SST.B Cir B Sat.Suction Temp. dF SSTB
