84
APPENDIX C: Navigatort Display
MODE -- RUN STATUS
ITEM EXPANSION VALUES UNIT WRITE STA TUS POINT
RUN STATUS Run Status Men\u
VIEW View Menu
MODE Operating Mode see Appendix B MODETEXT
SUBM O p e r a t i n g S u b --- M o d e see Appendix B SUBMTEXT
S.DMD System Demand see Appendix B SYS_DMDT
LINK Linkage Active Ye s/No Forcible LNK_ACT
OCC Currently Occupied Yes/No Forcible OCCUPIED
SAT S upply Air Temperature xxx..x °F SAT
COOL Cooling Status Menu
RDHL Requested Dehum Level 0=None,
1=Subcool,
2=Reheat
REQDHLEV
MC.ON Mechanical Cool active? Ye s/No MECHCOOL
MAX.C Max Allowed Cool Stages 0to3 Forcible MAXCSTGS
REQ.C Requested Cooling Stages 0to3 REQCSTGS
ACT.C Actual Cool Stage Active x ACTCSTGS
TG.A1 Compressor A1 Timeguard xxx sec TIMGD_A1
TG.AL Comp A1 Loader Timeguard xxx sec TIMG_ALD
FC.ON Free Cooling a ctive Yes/No FREECOOL
REQ.D Requested Damper Pos 0 to 100 % REQDAMP
HEAT Heating Status Menu
REQ.H Requested Heating Stages 0to2 REQHSTGS
ACT.H Actual Heat Stage Active x ACTHSTGS
MAX.H Max Allowed Heat Stages 0to2 Forcible MAXHSTGS
TG.H1 Heat Stage 1 Timeguard xxx sec TIMGD_H1
TG.H2 Heat Stage 2 Timeguard xxx sec TIMGD_H2
VENT Ventilation Status Menu
VENT Ventilation Status see Appendix B VENTTEXT
EC.MP MinPositioninEffect 0 to 100 % Forcible MIN_POS
OCC Currently Occupied Yes/No Forcible OCCUPIED
A.IO ASSIGNED INPUTS/OUPUTS
AI06 Assigned AI06 Function 0=None,
1=IAQ,
2=OARH,
3=RARH,
4=OAQ,
5=SPRH,
6=OACFM
MBBAI06F
AI07 Assigned AI07 Function 0=None,
1=IAQ,
2=OARH,
3=RARH,
4=OAQ
,5=SPRH,
6=OACFM
MBBAI07F
AI08 Assigned AI08 Function 0=None,
1=IAQ,
2=OARH,
3=RARH,
4=OAQ,
5=SPRH,
6=OACFM
MBBAI08F
DI02 Assigned DI02 Function 0=None,
1=COFS,
2=REMOCC
3=REMOFF,
4=FILTER,
5=ENTHALPY,
6=GEN STAT,
7=HUMIDISTAT,
8=IAQOVRD,
9=FANSTATUS,
10=PHASEMON
MBBDI02F
DI.Y3 Assigned MBB Y3 Function 0=None,
1=COFS,
2=REMOCC,
3=REMOFF,
4=FILTER,
5=ENTHALPY,
6=GEN STAT,
7=HUMIDISTAT,
8=IAQOVRD,
9=FANSTATUS,
10=PHASEMON
MBBDI09F
