140
Settings -- Main Menu Layout (cont)
DISPLAY TEXT EXP ANDED DISPLAY TEXT VALUES UNITS DEFAUL T POINT ENTRY
NEW HARDWARE (cont) Quick Menu for New Hardware
REM.SHUTDOWN CHAN Remote Shutdown Channel 0=None,
1=MBB DI12,
2=MBB DI13,
3=MBB DI14,
4=MBB DI02,
5=MBB Y3
0=NONE ROFFCHAN
COFS CHANNEL COFS Assigned Channel 0=None,
1=MBB DI12,
2=MBB DI13,
3=MBB DI14,
4=MBB DI02,
5=MBB Y3
0: No FIOP
4: FIOP
COFSCHAN
GEN STATUS CHAN General Status Channel 0=None,
1=MBB DI12,
2=MBB DI13,
3=MBB DI14,
4=MBB DI02,
5=MBB Y3
0=NONE GEN_CHAN
ENTHALPY SW CHAN Enthalpy Sw Channel 0=None,
1=MBB DI12,
2=MBB DI13,
3=MBB DI14,
4=MBB DI02,
5=MBB Y3
0=NONE ENTHCHAN
FAN STAT CHANNEL Fan Status Channel 0=None,
1=MBB DI12,
2=MBB DI13,
3=MBB DI14,
4=MBB DI02,
5=MBB Y3
0=NONE FNSTCHAN
IAQ OVERIDE SW CH IAQ override sw channel 0=None,
1=MBB DI12,
2=MBB DI13,
3=MBB DI14,
4=MBB DI02,
5=MBB Y3
0=NONE IAQOCHAN
PHASE MON CHANNEL Phase Monitor Channel 0=None,
1=MBB DI12,
2=MBB DI13,
3=MBB DI14,
4=MBB DI02,
5=MBB Y3
0: No FIOP
3: FIOP
PMR_CHAN
NETWORK SETTINGS Building Network Configurations Menu
BAS PROTOCOL BAS Protocol Select 0=NONE,
1=CCN,
2=BACNET
x 2=BACNET BMS_CFG
NETWORK TIMEOUT Network Input Timeout 0 to 600 min 30 NETINTO
CCN CCN Network Configuration Menu
BUS NUMBER CCN Bus Number 0 to 239 0 CCNBU S
CCN ELEMENT # CCN Element Number 1 to 239 1 CCNADD
CCN BAUDRATE CCN Baud Rate 0=9600,
1=19200,
2=38400
2=38400 BAUDENUM
BROADCAST ACK? CCN B roa dcast Ack’er Yes/No No CCNBCACK
BROADCAST SCHEDL? Global Schedule Broadcst Yes/No No CCN_GSBC
BROADCAST TIME? CCN Time Broadcast Yes/ No No CCNBC
BROADCAST OAT? Broadcast OAT On Network Yes/No No OATBC
BROADCAST OARH? Broadcast OARH On Netwrk Yes/No No OARHBC
BROADCAST OAQ? Broadcast OAQ On Network Yes/No No OAQBC
BROADCAST IAQ? Broadcast IAQ On Network Yes/No No IAQBC
ALLOW G. OVERRIDE Allow Global Overrides Ye s/ No Yes GLBLOVER
LOCATION Device Location text DEV_LOC
REFERENCE NUMBER Reference number text REF_NUM
BACNET BACnet network configuration menu
MAC ADDRESS BACnet Device Macaddress 1 to 127 01 BAC_MAC
BACNET BAUDRATE BACnet BMS baud rate 0=9600,
1=19200,
2=38400,
3=57600,
4=76800,
5=115200
4=76800 BAC_BAUD
AUTO ID SCHEME ALC Auto Id Scheme Ye s/ No Yes AUID
BACNET AUTO ID BACnet ID Auto ID Yes/No Yes BAC_AUID
BACNET ID BACnet ID Number 0 to 4194302 1610101 BAC_ID
LINKAGE SETTINGS LINKAGE SETTINGS MENU
DEVICE IAQ BACnet device for IAQ 0 to 4194303 1610100 DEVIAQ
OBJECT ID IAQ Object instance for IAQ 0 to 9999 1009 OBJIAQ
COV IAQ Change of value for IAQ 0to60 0 COVIAQ
DEVICE OAQ BACnet device for OAQ 0 to 4194303 1610100 DEVOAQ
OBJECT ID OAQ Object instance for OAQ 0 to 9999 1012 OBJOAQ
COV OAQ Change of value for OAQ 0to60 0 COVOAQ
DEVICE OARH BACnet device for OARH 0 to 4194303 1610100 DEVOARH
OBJECT ID OARH Object instance for OARH 0 to 9999 1022 OBJOARH
COV OARH Change of value for OARH 0to60 0 COVOARH
DEVICE OAT BACnet device for OAT 0 to 4194303 1610100 DEVOAT
OBJECT ID OA T Object instance for OAT 0 to 9999 1003 OBJOAT
