Carrier 58MCB080 - Maximum Allowable Vent Pipe Length; Performance Data Summary

15
58MCB
MAXIMUM ALLOWABLE EXPOSED VENT PIPE LENGTH (FT) WITH AND WITHOUT INSULATION
IN WINTER DESIGN TEMPERATURE AMBIENT*
* Pipe length (ft) specified for maximum vent pipe lengths located in unconditioned spaces. Vent pipes located in unconditioned space cannot
exceed the total allowable pipe length as specified in Maximum Allowable Pipe Length table.
† Insulation thickness based on R value of 3.5 per in.
Performance data
EFFICIENCY
* Capacity and AFUE in accordance with U.S. Government DOE test procedures.
† Gas input ratings are certified for elevations to 2000 ft. For elevations above 2000 ft, reduce ratings 2% for each 1000 ft above sea level. In Canada, derate
the unit 5% for elevations 2000 to 4500 ft above sea level.
‡ Airflow shown is for bottom only return-air supply. For air delivery above 1800 CFM, see Air Delivery table for other options. A filter is required for each
return-air supply.
ICS—Isolated Combustion System
UNIT
SIZE
WINTER DESIGN
TEMPERATURE
(°F)
MAX PIPE
DIAMETER
(IN.)
WITHOUT
INSULATION
WITH 3/8-IN. OR
THICKER INSULATION†
040-08
040-12
20 1-1/2 51 70
0 1-1/2 28 70
–20 1-1/2 16 70
060-08
060-12
060-16
20 2 65 70
0 2 35 70
–20 2 20 70
080-12
080-16
080-20
20 2-1/2 70 70
0 2-1/2 47 70
–20 2-1/2 28 70
100-16
100-20
20 3 70 70
0 3 50 70
–20 3 28 70
120-20
20 4 70 70
0 4 48 70
–20 4 23 70
140-20
20 4 70 70
0 4 57 70
–20 4 30 70
UNIT SIZE 040-08 040-12 060-08 060-12 060-16 080-12 080-16 080-20 100-16 100-20 120-20 140-20
CERTIFIED TEMP RISE RANGE (°F)
30—60 15—45 45—75 30—60 20—50 40—70 30—60 20—50 45—75 30—60 40—70 50—80
CERTIFIED EXT STATIC PRESSURE Heating
0.10 0.10 0.12 0.12 0.12 0.15 0.15 0.15 0.20 0.20 0.20 0.20
(In. wc) Cooling
0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50 0.50
AIRFLOW CFM‡ Heating
850 1125 885 1065 1320 1190 1285 1785 1315 1690 1720 1970
Cooling
895 1215 900 1200 1545 1245 1525 1925 1570 1930 2000 1990
UNIT SIZE 040-08 040-12 060-08 060-12 060-16 080-12 080-16 080-20 100-16 100-20 120-20 140-20
OUTPUT CAPACITY
BTUH* (ICS)
(Shaded capacities
are specified on
rating plate)
Direct
Vent (2-Pipe)
Upflow 37,000 37,000 56,000 56,000 56,000 74,000 74,000 74,000 93,000 93,000 112,000 127,000
Downflow 37,000 37,000 56,000 56,000 56,000 74,000 74,000 74,000 93,000 93,000 112,000 127,000
Horizontal 37,000 37,000 56,000 56,000 56,000 74,000 74,000 74,000 93,000 93,000 112,000
127,000
Non-Direct
Vent (1-Pipe)
Upflow 37,000 37,000 56,000 56,000 56,000 74,000 74,000 74,000 93,000 93,000 112,000 NA
Downflow 37,000 37,000 56,000 56,000 56,000 74,000 74,000 74,000 93,000 93,000 112,000 NA
Horizontal
37,000 37,000 56,000 56,000 56,000 74,000 74,000 74,000 93,000 93,000 112,000 NA
INPUT BTUH† 40.000 40,000 60,000 60,000 60,000 80,000 80,000 80,000 100,000 100,000 120,000 120,000
AFUE%
Nonweatherized ICS
Direct
Vent (2-Pipe)
Upflow 92.3 92.3 92.3 92.3 92.3 92.3 92.3 92.3 92.3 92.3 92.3 92.3
Downflow
91.2 91.2 91.2 91.2 91.2 91.2 91.2 91.2 91.2 91.2 91.2 91.2
Horizontal 92.1 92.1 92.1 92.1 92.1 92.1 92.1 92.1 92.1 92.1 92.1 92.0
Non-Direct
Vent (1-Pipe)
Upflow 92.1 NA
Downflow
91.0 NA
Horizontal 91 NA
