Carrier 58MCB080 - Concentric Vent (2-Pipe) Application Diagram

9
58MCB
C IN. DIA
B IN. DIA PVC
VENT/EXHAU
ST
1
3
/16
B IN. DIA PVC
INTAKE/COMBUSTION AIR
D
E
F
A
1
1
/2
A97110
DIMENSIONS (In.)
* Dimension A will change accordingly as dimension D is lengthened or shortened.
† Dimension D may be lengthened to 60 in. maximum. Dimension D may also be shortened by
cutting the pipes provided in the kit to 12 in. minimum.
KIT PART NO. A* BCD†EF
KGAVT0501CVT 33-3/8 2 3-1/2 16-5/8 6-1/4 5-3/4
KGAVT0601CVT 38-7/8 3 4-1/2 21-1/8 7-3/8 6-1/2
NOTE: See furnace Installation
Instructions when venting multiple
furnaces near each other.
CONCENTRIC VENT for Direct Vent (2-Pipe) Application (All Model Sizes)
CONDENSATE TRAP
1
⁄ 2 OD
INDUCER HOUSING
DRAIN CONNECTION
1
⁄ 4 OD
COLLECTOR BOX TO
TRAP RELIEF PORT
5
⁄ 8 OD
COLLECTOR BOX
DRAIN CONNECTION
1
⁄ 2 -IN. PVC OR CPVC
SCREW HOLE FOR
UPFLOW OR DOWN-
FLOW APPLICATIONS
(OPTIONAL)
1
4
2
7
8
1
8
7
SLOT FOR SCREW
HORIZONTAL
APPLICATION
(OPTIONAL)
WIRE TIE
GUIDES
(WHEN USED)
1
2
1
3
4
1
3
4
FRONT VIEW SIDE VIEW
FURNACE
DOOR
FURNACE
DOOR
CONDENSATE
TRAP
7
8
1
4
26
4
FURNACE
SIDE
FURNACE
SIDE
1
2
1
1
4
26
4
3
4
5
3
4
5
4
SIDE VIEW FRONT VIEW END VIEW FRONT VIEW
3
4
DOWNFLOW AND ALTERNATE
EXTERNAL UPFLOW APPLICATIONS
HORIZONTAL
APPLICATIONS
FIELD
DRAIN
CONN
FIELD
DRAIN
CONN
CONDENSATE
TRAP (INSIDE)
BLOWER SHELF
ALTERNATE DRAIN
TUBE LOCATION
UPFLOW APPLICATIONS
CONDENSATE TRAP
DRAIN TUBE LOCATION
A93026
