4
58MCB
Physical data
PSC—Permanent Split Capacitor
Carrier accessories
*
*
Factory-authorized and field-installed. Gas conversion kits are A.G.A./C.G.A. recognized.
† For 16 and 20 airflow sizes only (except 140-20 size unit). See kit Installation Instructions for details.
‡ Required for installation on combustible floors when no coil box is used, or when any coil box other than a Carrier cased coil is used.
N/A — Not Applicable
UNIT SIZE 040-08 040-12 060-08 060-12 060-16 080-12 080-16 080-20 100-16 100-20 120-20 140-20
DIRECT-DRIVE MOTOR
h.p. (PSC)
1/5 1/3 1/5 1/3 1/2 1/3 1/2 3/4 1/2 3/4 3/4 3/4
MOTOR FULL LOAD AMPS
4.9 5.8 4.9 5.8 7.9 5.8 7.9 11.1 7.9 11.1 11.1 11.1
RPM (Nominal) — SPEEDS
1075—31075—41075—3 1075—4
BLOWER WHEEL DIAMETER X WIDTH (In.)
10 x 6 10 x 7 10 x 6 10 x 7 11 x 8 10 x 7 11 x 8 11 x 10 11 x 8 11 x 10 11 x 10 11 x 10
FILTER SIZE (In.) — (Washable)
(1) 16 x 25 x 1 (1) 20 x 25 x 1 (1) 24 x 25 x 1
SHIPPING WEIGHT (Lb)
165 166 172 174 174 188 194 206 219 221 250 250
LIMIT CONTROL
SPST
HEATING BLOWER CONTROL (Off Delay)
Selectable 90, 120, 150, or 180 sec
BURNERS (Monoport)
223334445566
GAS CONNECTION SIZE
1/2-in. NPT
GAS VALVE (Redundant) Manufacturer
White-Rodgers
Minimum Inlet Pressure (In. wc)
4.5 (Natural Gas)
Maximum Inlet Pressure (In. wc)
13.6 (Natural Gas)
IGNITION DEVICE
Hot Surface
UNIT SIZE
040-08
040-12
060-08
060-12
060-16
080-12
080-16
080-20
100-16
100-20
120-20 140-20
GAS CONVERSION KIT—NATURAL-TO-PROPANE
KGANP4001ALL
GAS CONVERSION KIT—PROPANE-TO-NATURAL
KGAPN3301ALL
TWINNING KIT†
N/A KGATW0601HSI
N/A
MANUFACTURED (Mobile) HOME KIT
KGAMH0102KIT
N/A
DOWNFLOW BASE (For Combustible Floors)‡
KGASB0201ALL
VENT TERMINATION KIT (Bracket Only for 2 Pipes)
2-in.—KGAVT0101BRA 3-in.—KGAVT0201BRA
CONCENTRIC VENT TERMINATION KIT (Single Exit)
2-in.—KGAVT0501CVT 3-in.—KGAVT0601CVT
CONDENSTATE FREEZE PROTECTION KIT
KGAHT0101CFP
CONDENSATE NEUTRALIZER KIT (obtained thru RCD)
P908-0001
SIDE FILTER RACK (Without Filter) Upflow Only
KGAFR0200ALL
ELECTRONIC AIR CLEANER (EAC)
Model EACB
MECHANICAL AIR CLEANER
Models FILCAB, EZXCAB
HUMIDIFIER
Model HUM
HEAT RECOVERY VENTILATOR
Model HRV
ENERGY RECOVERY VENTILATOR
Model ERV
UV LIGHTS
Model UVL
DOOR GASKET KIT
KGBAC0110DGK
