REFRIGERATION CYCLE DIAGRAM
Fig. 6 — Heat Pumps
REFRIGERANT LINES
IMPORTANT: Both refrigerant lines must be insulated separately.
LIQUID SIDE
GAS SIDE
HEAT
EXCHANGE
(EVAPORATOR)
HEAT
EXCHANGE
(CONDENSER)
COMPRESSOR
ïWAY VALVE
ïWAY VALVE
ïWAY VALVE
COOLING
HEATING
T2 Evaporator
temp. sensor
T1 Room temp.
sensor
ACCUMULATOR
ROODTUOROODNI
CHECK VALVE
(Heating Model only)
CAPILLARY TUBE
