Fan Motor
Harness Plug
Compressor
Power Harness
Wires Yel, Red,
Blk
Fig. 40 – Compressor and Fan Harness
(Unit sizes 13 and 24B)
Fig. 41 – Compressor and Fan Harness
(Unit sizes 25, 36, 37, 48, 49 and 60)
