5
SOLENOID VALVE
SOLENOID VALVE
FIELD-SUPPLIED
TUBING
1/2 IN.
TUBING CLAMP (TYPICAL)
TUBE SUPPORT BRACKETS
TUBE SUPPORT BRACKETS
FIELD-SUPPLIED
TUBING
FIELD-SUPPLIED
TUBING
5/8 IN.
TUBING CLAMP
(TYPICAL)
SOLENOID VALVE
00PPN500000600A
TUBE ASSEMBLY
BALL VALVE
BALL VALVE
1/2 IN. CLAMP (TYPICAL)
BALL VALVE
CIRCUIT C
CIRCUIT B
CIRCUIT A
30RB210-300
Fig. 5 — Typical Piping Brackets (cont)
30RB120-190
