Carrier Performance 38QRR - TROUBLESHOOTING (CONT.); NO COOLING OR INSUFFICIENT COOLING

10
TROUBLESHOOTING (CONT.)
LEGEND
NOTE: For systems with indoor units equipped with microprocessor
control, see se
p
arate controls, service, and troubleshootin
g
manual.
NC — Normally Closed
ODT — Outdoor Thermostat
A07436
Fig. 11 --- Troubleshooting the Heating Cycle
