20
Table 6 -- Dry Coil Air Delivery* -- Horizontal and Downflow Discharge -- Unit 50VR---- 24--60 Without Advanced Dehumidification (AD) FIOP 460VAC Models
UNIT
MOTOR SPEED WIRE COLOR
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0
A60
Low Blue
CFM 1415 1384 1340 1314 1270 1236 1192 1159 1116 1076
BHP 0.32 0.34 0.35 0.36 0.37 0.39 0.39 0.41 0.42 0.44
Med-Low
1
Pink
CFM 1454 1405 1364 1316 1281 1234 1198 1147 1105 1056
BHP 0.34 0.35 0.36 0.37 0.38 0.40 0.41 0.42 0.43 0.45
Medium
2
Red
CFM 1818 1770 1731 1693 1657 1621 1579 1546 1505 1436
BHP 0.56 0.57 0.59 0.60 0.62 0.63 0.64 0.66 0.67 0.66
Med-High Orange
CFM 1881 1849 1818 1793 1763 1729 1679 1610 1523 1479
BHP 0.67 0.69 0.70 0.71 0.72 0.73 0.73 0.71 0.68 0.65
High Black
CFM 2138 2084 2025 1967 1893 1829 1754 1678 1591 1475
BHP 0.98 0.95 0.93 0.90 0.86 0.84 0.80 0.76 0.74 0.68
* Air delivery values are without air filter and are for dry coil (See Wet Coil Pressure Drop table).
1
Factory---shipped low stage cooling speed.
2
Factory---shipped high stage cooling speed.
Note: Deduct field---supplied ai r filter pressure drop and wet coil pressure drop to obtain external static pressure available for ducting.
50VR
