Carrier PIC 5+ - Page 37

37
Compressor components
Weight (kg)
Power Train Assembly(Include Motor Stator, Rotor Assembly and 2nd Stage Lube Support)
1000
2nd Stage lube support
75
Rotor Assembly (Include Motor Rotor, 1st Stage Lube Support)
310
1st Stage Lube Support
70
1st Stage Suction Assembly(Include 1st Stage Blade Ring, 1st Stage Suction Housing)
379
1st Stage Blade Ring Assembly
79
1st Stage Suction Housing
281
2nd Stage Suction Assembly(Include 2nd Stage Blade Ring, 2nd Stage Suction Housing)
351
2nd Stage Blade Ring Assembly
60
2nd Stage Suction Housing
274
1st Stage Volute
613
2nd Stage Volute
478
1st Stage Shroud
225
2st Stage Shroud
200
1st Stage IGV Shroud
54
2st Stage IGV Shroud
44
1st Stage Impeller
29
2st Stage Impeller
27
Miscellaneous
172
Total Weight (Excludes Motor Stator and Motor Rotor )
2810
Table 3 - 19DV Compressor weights
COMPRESSOR FRAME
MOTOR CODE
STATOR & HOUSING WEIGHT
(kg)
ROTOR & SHAFT WEIGHT
(kg)
DV4
NB
494
150
DV4
ND
522
154
DV4
NF
558
159
DV4
NH
597
165
Table 4 - 19DV motor weigths
VFD type
Frame
Weight (kg)
LF2 Rockwell 608 Amps
2CC
1180
LF2 Rockwell 900 Amps
4AA
1590
Danfoss
E
300
Table 5 - 19DV VFD weights
