Carrier TSTATCCNAC01-C User Manual

A04105
NON-PROGRAMMABLE THERMOSTAT CONFIGURATION RECORD
Date
Owner/Operator
A) Hardware Configuration
Seal hole in wall.
Thermostat Model No.
B) Mode Settings
C) Configuration Options
Mode (Off, Heat, Cool, Auto, Eheat)
Heating Set Point Value
Cooling Set Point Value
Fan (Auto or On)
1 Anticipator (1-9: factory default = 3)
2 Clean Filter Timer (Off or 1-9: factory default = 2)
3 Fahrenheit or Celsius (F or C: factory default = F)
4 Fan On with W/W1 output (Off or On: factory default = Off)
5 HP (2-speed) / AC Configuration
6 Cooling Lockout (Off or On: factory default = Off)
7 Zoning Selection (Off or On: factory default = Off)
8 Auxiliary Heat Lockout (Off or 5-55°F: factory default = Off)
9 N/A
10 O(Reversing Valve) ON with Heat or Cool (present on Heat Pump models only.
11-12 N/A
13 Room Temperature Offset (-5 to +5: factory default = 0)
14 N/A
15 Enable Auto Mode (Off or On: factory default = On)
16-17 N/A
18 Backlight Configuration: (On = Continuous; Off = Backlight with Keypress; Default = Off)
19 Equipment Present (2, 3, 4); Default = 4
20 N/A
21 Keypad lockout (Off or On: Default = Off)
Copyright 2004 CARRIER Corp. • 7310 W. Morris St. • Indianapolis, IN 46231 tstat-30si
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book
TabPC 101 Catalog No. 03TS-TA54 Printed in U.S.A. Form TSTAT-30SI Pg 12 08-04 Replaces: New
