ALARM LIST
ALARM ALARM DESCRIPTION
A00 No Malfunction
A01/A02 High or Low Pressure Switch
A04 Road Compressor Clutch
A06 Condenser Fan Motor (high amp draw)
A07 Evaporator Fan Motor (high amp draw)
A09 Hot Gas Valve (HGS1) (high amp draw)
A10 Quench Valve (BPV) (high a mps draw)
A11
Condenser Pressure Control Valve
(HGS2)
A12 High Temperature Alarm
A13 Low Temperature Alarm
A14 Defrost Cycle Is Greater Than 45 Minutes
A15 Setpoi nt out of range --20.2_Fto86_F
2EP
Functional parameters have not been set
or have been lost. Press and hold the
SETkeytoclearthealarm.
EE Return Air Sensor
bAt Low Battery Voltage
Err Programming error by user.
-- -- --
Setpoint lower than maximum setpoint
but in the range --20_Fto86_F
