Carrier X Series User Manual

4
62--10892
SYMBOLS USED ON CAB CONTROL
Readout
Standby operation display (Not Applicable)
Road operation display
Manual defrost control key
Unit start-up key
Unit shut-down key
Data selection key
Selected data decrease key
Selected data increase key
Unit operation display
S Green = in-range (left half)
S Red = malfunction (right half)
