19 // GB
Throttle Trim
If RC model moves on its own accord when throttle trigger is in
neutral, adjust throttle trim.
Steering Trim
When model
goes left.
When model
goes right.
When the RC model does not run straight, adjust the steering trim.
Allow the model to move without adjusting the steering wheel so
that you can establish the direction of travel and correct it by pus-
hing the steering trim in the opposite direction from the direction in
which the model is moving.
When the
model is going
backwards
When the
model is going
forwards
Specifications
Transmitter Frequency 2.4 GHz FHSS
Power supply DC 4.8 - 6 V=
Weight 630 g
Receiver Power Supply DC 4.8~6.0 V (Battery box or via BEC-system from driving battery)
Dimensions 35 x 26 x 14 mm
Weight 10 g
It is CARSON’s policy that we strive to improve the quality of our products. Therefore CARSON may alter specifications of our products at
any time without any notice.
