Function Version REFLEX WHEEL PRO3
Connectors
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. CH3 servo (CH3)
4. CH4 servo (CH4)
5. CH5 servo (CH5)
BEC: Power connector for BEC
Connectors
1. Steering servo (CH1)
2. Throttle servo (CH2)
3. CH3 servo (CH3)
4. CH4 servo (CH4)
B/C: Power connector
Failsafe Set
Failsafe Pro + Set
Switch
Switch
ST trim
ST-D/R
TH trim
TH-D/R
Steering
wheel
Bat box
Power
Status LED
Servo reverse switch
Throttle trigger
Switch for Channel 3
Charger
Grip handle
REFLEX WHEEL PRO3 VERSION
WITHOUT BEC
REFLEX WHEEL PRO3 VERSION
WITH BEC
