Page 10 of 16 SA-441-10 Installation and Operating Instructions
11/1/19 CP5203A
OPERATION
GENERAL
This unit is designed for easy operation under the stress associated with high-speed pursuit. Most
siren functions are accessible with one simple motion without repetitive activation of switches or auto-
matic timed switching that can interfere with desired operation.
SELECTOR SWITCH
The 6-position rotary selector switch controls the primary operating
mode of the siren.
Radio - Also known as Radio Repeat, this function amplifies a radio
speaker input for re-broadcast outside the vehicle. The radio must
be connected and RADIO VOLUME ADJUSTed for this mode to
function.
Horn - A standby (silent) mode that may be overridden anytime with
the Siren push-button to produce a simulated Air-horn tone. Horn
tone may be disabled.
See OPTION SWITCHES section.
Manual – The siren tone rise and fall is manually controlled with
Siren push-button.
Wail - A slower changing tone used on highways.
Yelp - A rapidly changing tone used in congested areas.
Phaser - A very rapidly changing tone used at intersections or in
highly congested areas. May be disabled or optionally replaced
with Two-Tone which is two alternating frequencies like a European HI-LO. See OPTION SWITCHES
section.
SIREN SWITCH
This momentary push-button switch provides Manual tone control and various
tone overrides depending on the Selector switch setting. It can optionally control
Horn Ring Cycler 2 operation in the Horn position if the HRC2 option is selected.
See OPTION SWITCHES section.
With the Dual switch OFF, the following functions are available:
Sound Hazard - Sound level from siren speaker (>120dBA @ 10 feet) may cause hearing damage.
Do not operate siren without adequate hearing protection for you and anyone in immediate vicinity.
(Ref. OSHA 1910.95 for occupational noise exposure guidelines)
SELECTOR SWITCH
RADIO
HRN/TT
MAN
WAIL
YELP
PHASR/W_Y
SIREN
Selector
Switch
Operating
Mode
Activate Siren push-button or Auxiliary Input Override
Radio Radio No Change
Horn Silent Horn (Default) or HRC2 (See OPTION SWITCHES section)
Manual Silent Manual siren tone
Wail Wail Toggle between Wail and Power C
Yelp Yelp Horn
Phaser Phaser Horn
To Next Page
