Carson SA-441-10F - Control Head Installation Template; Template Dimensions and Usage

SA-441-10 Installation and Operating Instructions Page 15 of 16 CP5203A 11/1/19
2-7/8”
2-1/2”
5-1/4”
2-5/8”
5-7/8”
6-1/4”
1/2”
1/8”
This inner area to be
removed.
CAUTION: Please note that top and bottom edges only provide 1/8” overlap. Cut carefully.
CONTROL HEAD INSTALLATION TEMPLATE
