AXLE
REF NO PART NO DESCRIPTION REQD NO
1 5272503 AXLE 1
2 5202503 HUB 2
3 5232503 DRIVE SPROCKET 1
4 5522508 BRAKE DISK 1
5 3221001 LUTCO BEARING 20MM w/FLANGE 2
6 3221009 ECCENTRIC LOCK COLLAR (SE20K) 2
7 F245 BOLT CARRRIAGE 5/16"18 X 3/4" NC 4
8 F1017 NUT FLANGE LOCK 5/16" WHIZ 5
9 5002517 PARALLEL FLAT KEY A M5X50 3
10 3311105 CHAIN #35-58 PITCHS 1
11 5183014 6.000.171 WHEEL RR KEYED 1
12 5183013 6.000.170 WHEEL RR W BEARINGS 1
13 5162504 TIRE 13X500-6 2
14 5001037 9.800.016 M16 NUT,CASTLE 1
15 5001088 9.800.012 M12 NUT,CASTLE 1
16 5203004 7.020.039 HUB COVER, 2
17 5192504 6.000.183 RIM KEYED 1
18 5192505 6.000.198 RIM BEARING 1
19 5222504 9.030.009 BEARING,6201 1
20 5222503 9.030.010 BEARING,6202 1
21 5001112 9.106.016 BOLT M6X16 8
22 5001086 9.400.006 LOCK WASHER M6 8
23 5001115 SET SCREW - MT HUB 4
