13
EFFECTS ALGORITHMS
EFFECTS ALGORITHMS
DELAY • ROTARY SPEAKER • EQ
DELAY/ECHO
Use the DELAY/ECHO effects to simulate “canyon-like” reflections for guitar, vocals. drums etc... Also use it for correct-
ing time delays in speaker systems. Please see page 15 for “Delayed Loudspeakers”.
80-90 Misc. Delays
DELAY PARAMETERS
d-Select LO for subtle delay effects (0-495), or select HI (500-595) for a more dramatic effect.
dL-Left delay time.
dR-Right delay time.
rL-Left regeneration time. The higher the number, the longer the echo decay.
rR- Right regeneration time. The higher the number, the longer the echo decay.
fL&fR-Loop low pass filter for the right or left signal (when in stereo mode).
ROTARY SPEAKER
This effect reproduces the classic sound of a rotating speaker such as the old “Leslie” speaker. This is a great effect
for guitar and keyboards.
90-94 Rotary Speaker
ROTARY SPEAKER PARAMETERS
Sr-Rotary speed slew selection. The difference in the rate of speeds between the woofer and the tweeter.
rS-Rotor speed.
dS-Drum speed-Speed of rotation.
dP-Rotary pan depth/Cabinet height.
rP-Rotary pan depth/Dispersion level.
EQ
The digital EQ provides +6dB to -12dB for Low Mid and High frequencies as well as phase adjustment.
95-99 EQ
EQ PARAMETERS
Pl-Phase.
L-Low.
C-Mid.
H-High.
