CasaCam BC200 - Technical Specifications; Kit and Wireless Specs; Camera Hardware Specs; Monitor Hardware Specs

9
Specification
Kit
OperatingFrequencyRange 2.4GHz
TXPower 17dBm
RXSensitivity ‐88dBm
Type of Spread Spectrum
Used
FHSS
TypeofModulationUsed GFSK
DataRate 4Mbps
CommunicationRange 300M
Thetransmissionrangeofthewirelesssignal
mayweakenaccordingtoyourenvironment.
Camera
Imagesensortype 1/4"ColorCMOSImagesensor
EffectivePixel 1280(H)x1024(V)
Powerrequirement 5VDC1.5A
ImageResolution 10fps@1280*720
Lens 3.95mmF2.2
ViewingAngle(Diagonal) 55°(FOV)
IRLED/NightVisionRange 5m940nm
Operation temperature ‐10~40°C
Monitor
LCDPanelsize 5"touchpanel
LCDResolution 800x480
OperatingTe mperature 14°F~104°F(‐10~40°C)
OperatingHumidity 0%~85%
Powerrequirement 5VDC1.5A
