cascade corporation 35E - Slipsheet Loads; Loads with Torn Slipsheet Tabs

4 684945-R5
PP0129.eps
PP0130.eps
S
LIPSHEET LOADS
Unitized loads
Nonskid coating
recommended
Transport
Stack behind fold
Tilt
Banding OR Stretchwrap
1
/4 in.
3-4°
Tilt
1
Wall
OR
Second
Load
2
Wedge both tips under
slipsheet. Drive forward.
1
/4 in.
Position load 6 in. over new slipsheet.
Lower platen onto slipsheet.
4
Push off load.
Postion 1/4 in.
behind fold.
5
Raise platen.
Drive in reverse
3
Tab
Loads with Torn Slipsheet Tab
