cascade corporation 35E - Unloading; Unloading on Stacks; Unloading on Pallets; Pallet Boards in Line with Push Direction

7 684945-R5
PP0135.eps
PP0136.eps
U
NLOADING ON STACKS
4
1
Position load 6 in. from load
edge, 1/2 in. above load.
3
Drive in reverse and lower
slightly as load is pushed
5
Lower and
tilt
Match load corners
1-2°
Tilt
2
1
/2 in.
2
Position load 6 in. over pallet.
Lower platen onto pallet.
U
NLOADING ON PALLETS
Pallet Boards in line with Push Direction
Tilt
3
Push load to
pallet edge
4
Raise platen slightly
1
3-4°
5
Drive in reverse
as load is pushed
6 in.
