cascade corporation 35E - Loading from Stacks; Loading from Truck Trailers

6 684945-R5
PP0133.eps
PP0134.eps
L
OADING FROM STACKS
4
Pull load
OPTIONAL: Pull and drive forward.
Raise platens as load is pulled on.
3-4°
2
Sheet tab in gripper
3
5
Lower
and tilt
1
Square tips to load
Tilt
Platen tip just below tab
4
3
Pull load
OPTIONAL: Pull and drive forward
2
Sheet tab in
gripper
Dockplate
required
CAUTION: Trailer wheels
must be locked
L
OADING FROM TRUCK TRAILERS
Tilt
1
3-4°
Sideshift to square load and
make room for removal
CAUTION: Level trailer with dock. Watch for nails or screws on trailer floor and walls.
