cascade corporation 35E - Loading; Loading from Floor; Loading from Pallets

5684945-R5
PP0131.eps
PP0132.eps
L
OADING FROM FLOOR
5
Tilt
4
Pull load
OPTIONAL: Pull and drive forward
2
Tilt
Sheet tab in gripper
3
3-4°
Square tips to load
1
L
OADING FROM PALLETS
Tilt
2
Sheet tab in gripper
1
3-4°
1 in.
Raise platens 1 in.
above pallet
4
Pull Load.
OPTIONAL: Pull and drive
forward
Tilt
5
3
