Cascadia CM200 User Manual

7929 SW Burns Way Phone: 503 344-5085
Suite F
Wilsonville, OR sales@cascadiamotion.com
1/14/2021 RMS PM Hardware User Manual 50 of 54
Description
Parameter
Value
Switch to Ground Inputs ( DIN1-4 )
Voltage level for “ON”
V
STG-ON
<0.9 V
Voltage level for “OFF”
V
STG-OFF
>4.2 V
Pull-up resistor to 5V
V
STG-PU
2.4 kΩ
Maximum Voltage on Input
V
STG-MAX
18 V
Switch to Battery Inputs ( DIN5-8 )
Voltage level for “ON”
V
STB-ON
>2.5 V
Voltage level for “OFF”
V
STB-OFF
<1.3 V
Pull-down resistor
R
STB-PD
10 kΩ
Maximum Voltage on Input
V
STB-MAX
18 V

Cascadia CM200 Specifications

General

Input Voltage	24V DC
Operating Temperature	-20°C to 60°C
Communication Protocol	Modbus TCP/IP, Modbus RTU
Communication	Ethernet, RS-485
Protection Features	Over-voltage, Over-current, Short circuit
