Engine-Engineandcrankcase
42.Positionaxedstand(3)underthesupportofthe
groove(1)ofthefrontaxledriveplacingawooden
plugbetweenparts(3)and(1).
WLAPL4S10C133A36
43.Setastandunderthebackoftheenginesoastobe
abletoreleasethehoistwiththecouplingdevicein
fullsafety.
Addaropeorchainalsoonthefrontoftheengine
andtakeuptheslackwiththeliftingdevice,keeping
theenginebalanced.
WLAPL4S10C136A37
44.Removethebolts(1)fasteningthefrontaxlesupport
(2)totheengine.Removetheadjusterspacersfor
thesupport-monobloc(4)/sump(3).
WLAPL4S10C141A38
45.Checkthattherearenobracketsbetweentheengine
andthecoolingassembly,detachtheengine(2)from
thefrontaxle,(3)tryingtoavoidincorrectmovements
withthehoistinordernottodamagetheradiatorns
(1)withtheenginefan.Resttheengine(2)ona
support.
WLAPL4S10C138A39
