CHAPTER 2
10 Case IH 3230/3240/3320/3330/3340 & 4420/4430/4440, Model Year 2010 & Newer ISO AutoBoom® Installation Manual
Sensor - Left Ultrasonic 063-0130-012 1
Sensor - Right Ultrasonic 063-0130-014 1
Sensor - Center Ultrasonic 063-0130-018 1
Bracket - Valve Mounting 107-0171-802 1
Bracket - Sensor Mounting 107-0172-501 2
Cable - 70’ Ultrasonic Sensor Extension 115-0171-527 2
Cable - AutoBoom Harness 115-0230-032 1
U-Bolt - 2-1/16” W x 3” L x 3/8” Thread 107-0171-609 4
U-Bolt - 3-9/16” W x 4” L x 3/8” Thread 107-0172-471 2
U-Bolt - 2-9/16” W x 3-1/2” L x 3/8”
Thread
107-0171-616 4
Bolt - 5/816”-18 x 7/8” Hex 311-0052-104 4
TABLE 2. UltraGlide Installation Kit (P/N 117-0232-129)
Picture Item Description Part Number Qty.
