Case IH 3340 - Optional Wheel Kit - 90-100 Booms

P/N 016-0230-129 Rev. A 13
INTRODUCTION
OPTIONAL WHEEL KIT - 90’-100’ BOOMS
Bolt - 3/8”-16 UNC x 1-1/4” Hex 311-0054-081 8
Nut - 3/8”-16 Zinc Flanged Lock 312-1001-164 16
TABLE 5. Optional Wheel Kit (P/N 117-0134-006)
Picture Item Description Part Number Qty.
Axle Assembly - Right Cushioned AutoBoom 063-0131-585 1
Axle Assembly - Left Cushioned AutoBoom 063-0131-590 1
Bracket - Left Weldment Receiver 116-0159-544 2
Bracket - Hub Retainer 107-0171-617 2
Wheel 322-0131-008 2
U-Bolt - 2-1/16” W x 3” L x 3/8” Thread 107-0171-609 4
U-Bolt - 1-5/16” W x 2” L x 3/8” Thread 107-0171-612 4
TABLE 4. Inner Ultrasonic Installation Kit (P/N 117-0137-026)
Picture Item Description Part Number Qty.
