Case IH LB333 - Page 50

SECTION 1 - GENERAL INFORMATION AND SAFETY
1ï16
22
movement when threading the needles or when carrying out maintenance work in the knotter area.
ACCESS TO MACHINE COMPONENTS
continuing to bale. 23
At all times the safety guards covering the access to the
baler components must be closed and latched while the
baler is in operation.
Whenever guards bearing safety decals need to be
replaced, ensure the corresponding safety decal is
ordered together with the guard and is adhered to the
guard immediately upon receipt. The part number of
the safety decal is mentioned on the decal.
For safety's sake and according to European
standards, safety guards now have locking devices
which can only be opened by turning the hex head
screw one quarter of a turn counter-clockwise with a
screwdriver, a coin or a wrench (key width 13 mm).
The latches are automatically engaged when the
safety guards are closed.
Replace defective latches immediately.
Pick-up guards are secured for safety.
24
