Case IH Magnum 310 - General Specification - Power Train

INTRODUCTION
Generalspecication-Powertrain
Transmission-Powershift
Standard18speedfullpowershift
withhydraulicallyactuatedclutches
Speedselection18forwardand4reverse
Optional23speedfullpowershift(includescreeper)
withhydraulicallyactuatedclutches
Speedselection23forwardand6reverse
Optional19speedfullpowershift
withhydraulicallyactuatedclutches(40km/hor50km/h)
Speedselection19forwardand4reverse
Shiftcontrol
Electronicallycontrolledswitchactuated
OilcoolerTransmission,hydraulic,steeringandbrakeuid
Transmission-ContinuouslyVariableTransmission(CVT)
Type
HydraulicCVT,inputcoupled
Pumptype
Variabledisplacement(swashplate)
Motortype
Fixeddisplacement(bentaxis)
Numberofmechanicalranges
Forward4
Reverse4
Outputshaftspeedinforward(RPM)
Group49tires40km/h(24.9mph)=2931RPM
50km/h(31.1mph)=3656RPM
Group48tires40km/h(24.9mph)=3100RPM
50km/h(31.1mph)=3850RPM
Maximumreversespeed
Limitedto25km/h(15.5mph)
Brakes
Type
Hydraulic,power-assisted,self-adjusting
multiplewetplatetypedifferentialbrakes
Axledifferentialandplanetaries–MechanicalFrontDrive(MFD)axles
Axletype
Class4.5xed-4pin,12bolt
electricallycontrolled,
Class4.75xed-3pin,12bolt
engagedwithspringpressureclutch,
Class4.75saddlesuspended-3pin,12bolt
disengagedhydraulically
Class5.0xed-3pin,12boltFulllocking,electronicallycontrolleddifferential
Class5.0saddlesuspended-3pin,12bolt
Class5.0widexed-3pin,12bolt
Class5.0widesaddlesuspended-3pin,12bolt
Interaxleratio–Front/Rear
*Frontaxlereductionratio–Magnum™250and280
Class4.5xed
1.32277
*21.525
Class4.75xedandsaddlesuspended
1.32431
*21.500
*Frontaxlereductionratio–Magnum™310and340
Class4.75xedandsaddlesuspended
1.32716
*21.500
Class5.0andclass5.0widexedandsaddlesuspended
1.32204
*21.583
*Thisrationumbercanbefoundontheaxleserialnumberplate.
5143149922/02/2018
22
