INTRODUCTION
*Frontaxlereductionratio–Magnum™380
Class5.0xedandsaddlesuspendedandclass5.0wide
1.32454
*21.583
*Thisrationumbercanbefoundontheaxleserialnumberplate.
*Frontaxlereductionratio–Magnum™Rowtrac™310,340and380
Class5.0xedandsuspendedandclass5.0wide
1.34927
*21.583
*Thisrationumbercanbefoundontheaxleserialnumberplate.
Parkbrakesystem
Parkbrake
Springappliedmultipledisc
actuatedbytransmissioncontrollever
Powersteering
Type
Priorityondemandfromaxialpistonpump
Steeringpump
Hydrostatictype
Steeringcylinder
Doubleactioncylinder
Remotehydraulicsystem
PumpAxialpistonpump,pressure
andowcompensated
Typeremotevalve
Closedcenter,
allsectionsloadcheck“B”port(raise)
and“A”port(lower)
variableowcontrolforeachsection
Standardremotesystem*–Allmodels166l/min(44USgpm)
Optionalhighowremotesystem*–Allmodels224l/min(59USgpm)
OptionalTwinFlowremotesystem*–Allmodels282l/min(75USgpm)
Systempressure-standard21000kPa(3045psi)
Systempressure-TwinFlow21000kPa(3045psi)
CouplingsISOandASAE/ASABEcompatible
fastremovalbreakawaytype
*Systemowat2000RPM
RearPowerTake-Off(PTO)
PowerT ake-Off(PTO)typeIndependentoftransmission
Clutchtype
Hydraulicactuated
Rotation
Clockwisefromrearoftractor
Outputshaftsize(ifequipped)
540RPM
6splines,34.9mm(1.375in)diameterPTOshaft
1000RPM
21splines,34.9mm(1.375in)diameterPTOshaft
1000RPM
20splines,44.5mm(1.75in)diameterPTOshaft
Enginespeedfor540RPMand1000RPM
PTO
1803RPM
PTOoverspeedwarning540RPMand
1000RPMPTO
621RPM/1150RPMPTO
FrontPowerTake-Off(PTO)–1000RPM
PTOtypeIndependentoftransmission
Clutchtype
Hydraulicactuated
ImplementPTOkW(Hp)rating147kW(200Hp)maximum
Outputshaftsize(ifequipped)6spline,34.9mm(1.375in)diameterPTOshaft
21spline,34.9mm(1.375in)diameterPTOshaft
5143149922/02/2018
23
