INTRODUCTION
Rotation
6spline–counterclockwiserotationwhenviewedfromthefrontof
thetractor
21spline–clockwiserotationwhenviewedfromthefrontofthetarctor
Enginespeedfor1000RPMPTO
1803RPM
Drawbar
CatIII(Magnum™250,280,310)standardoryoketype
Fullswing,slidemount,
takesa38.1mm(1.5in)diameterpin
CatIV(Magnum™340and380)standardoryoketype
Fullswing,slidemount,
takesa50.1mm(2.0in)diameterpin
Rearhitchsystem
CatIII(Ifequipped)hitchtypeThreepoint(convertibletoIIIorIIIN)
OECDliftcapacityat610mm(24in)behindliftpoint(Manufacturer’sestimates)
Standardhitch
Magnum™250and280
6750kg(14900lb)
Magnum™310
7480kg(16500lb)
Optionalhitch
Magnum™250and280
7480kg(16500lb)
CatIVN(Ifequipped)hitchtypeThreepoint(convertibletoIIIorIVN)
OECDliftcapacityat610mm(24in)behindliftpoint(Manufacturer’sestimates)
Standardhitch
Magnum™340and380
8840kg(19500lb)
Optionalhitch
Magnum™280and310
8840kg(19500lb)
Draftarmtype
Rigidwithintegralquickcoupler
Positioncontrolanddraftcontrol
Electronic
Fronthitchsystem
CatIIIN(Ifequipped)hitchtype
Threepointclawend
Ballend(MIN)4090kg(9000lb)
OECDliftcapacityat610mm(24in)
forwardofliftpoint(Manufacturer’s
estimates)
3400kg(7500lb)
DraftarmtypeClawend
Positioncontrol(ifequipped)
Manual
Trackandundercarriage(ifequipped)
TrackdrivetypeIndependent,two-trackpositivedrive,
self-tensioningtracksystem
TrackundercarriageIntegralcenterpivotdesign,
10degreesup/downoscillation
Tracktype
Self-cleaningrubberbelt
Trackwidthstandard
406mm(16in)
Trackwidthoptional
457mm(18in)
Trackwidthoptional
610mm(24in)
Trackwidthoptional
762mm(30in)
Groundsurfacelength1788mm(70.4in)
Trackgauge(centertocenter)1930mm(76in)
Trackgauge(centertocenter)2032mm(80in)
Trackgauge(centertocenter)2235mm(88in)
Trackgauge(centertocenter)3048mm(120in)
Trackgaugeeldkit(centertocenter)3454mm(136in)
