SECTION 58 - DRIVELINES - CHAPTER 1
58-12
3. The grease bushing, 1, is retained on the tube
with two burrs, 2; install the bushing onto the new
tube and lightly tap it until it is seated.
BELT TENSION JACKSHAFT
Disassembly
1. Remove the PTO shaft from the front of the
jackshaft by twisting the locking ring, 1,
counter-clockwise and sliding the PTO shaft, 2,
off.
2. Remove the PTO joint shielding, 2, by removing
the two cap screws and locknuts, 1.
600-3-29
1
2
30
A3679-29
1
2
31
32
