INTRODUCTION
Track
Component
Torque
Masterlinkbolts(UseLOCTITE®242®onmasterlink
bolts.)
340.0-380.0N·m(250.8-280.3lbft)
Standardlinkshoebolts381.0-435.0N·m(281.0-320.8lbft)
FinalDrives
Component
Torque
DriveHubRollingT orque
8-15N·m(71-133lbin)
InputShaftBearingRetainerPlateMountingBolts77-87N·m(57-64lbft)
ParkBrakeHousingPlate
77-87N·m(57-64lbft)
BrakeHousingCover-M20X5012pnt650-730N·m(479-538lbft)
BrakeLineFitting
55-60N·m(41-44lbft)
BrakeBleederFitting
24-30N·m(18-22lbft)
CounterShaftBearingRetainerPlateMountingBolts125-150N·m(92-111lbft)
SpindleHousing310-380N·m(229-280lbft)
RingGearRetainingPlate310-380N·m(229-280lbft)
SunGearShaftRetainingPlate125-150N·m(92-111lbft)
OutputGearBearingRetainerPlateMountingBolts125-150N·m(92-111lbft)
PlanetaryCarriertoDriveHub310-380N·m(229-280lbft)
FinalDrivetoFrameMountingBolts
656-725N·m(484-535lbft)
FillCheckPlug24-30N·m(18-22lbft)
DrainPlug
24-30N·m(18-22lbft)
CabMounting
Component
Torque
Supportmountbolts733-854N·m(541-630lbft)
Brushguardmountbolts(ifequipped)587-794N·m(433-586lbft)
AirConditioningCompressor
Component
Torque
Compressorrotorshaftnut15-20Nm(11-15lbft)
Oilllerplug15-24Nm(11-18lbft)
Dustcoverscrews
7-11Nm(5-8lbft)
LiftCylinder
Component
Torque
Pistonbolt
1820-1600N·m(1342-1180lbft)
Gland135-542Nm(100-400lbft)
TiltCylinder
Component
Torque
Pistonbolt
2160-2450N·m(1593-1807lbft)
Gland135-542Nm(100-400lbft)
AngleCylinder
Component
Torque
Pistonbolt
2160-2450N·m(1593-1807lbft)
Gland135-542Nm(100-400lbft)
RipperCylinder
Component
Torque
Pistonbolt
1600-1820N·m(1180-1342lbft)
Gland135-542Nm(100-400lbft)
