Case 1150M Tier 2 - Torque - Special Torques

INTRODUCTION
Torque-Specialtorques
1150M
Ripper
Component
Torque
Rippermountingbolts
700-1260Nm(515-925lbft)
Ripperpinretainingandtubecoverbolts
145-260Nm(110-190lbft)
HydraulicPump
Component
Torque
NonPTOpump
Coverbolts66-80Nm(50-60lbft)
PTOtypepump
Airvent
9Nm(80lbin)
Pumphousingbolts
271Nm(200lbft)
PTOshaftretainer68Nm(50lbft)
SetscrewPTOshaftretainer9Nm(80lbin)
Shaftcoverscrews8-9Nm(65-75lbin)
FuseandRelayBlocks
Component
Torque
Fuseblockmounting
2.7Nm(24lbin)
Bussedstuds
8.5Nm(75lbin)
PowerRelays
Component
Torque
Outputstuds5.4Nm(48lbin)
Inputstuds
16.3Nm(144lbin)
EngineMounts
Component
Torque
Enginemountboltstochassis
205-230Nm(151-170lbft)
Rearenginemountbracketstobellhousing
118-133Nm(87-98lbft)
Frontenginemountbrackettoengineblock
118-133Nm(87-98lbft)
Startermountingbolts68-77Nm(50-57lbft)
EnginetoPumpsDriveShaft
Component
Torque
Flywheelmountbolts
285-305Nm(210-225lbft)
PumpsandMotors
Component
Torque
Pumpmountboltstoframe68-81Nm(50-60lbft)
Motormountboltstonaldrives250-280N·m(184-207lbft)
Pumptomotorhosesspitangeclamps90-100Nm(66-74lbft)
Inlethoseclamps
6.5-7.6Nm(58-68lbin)
RearFrameCover
Component
Torque
M24hexbolts
449-725N·m(331-535lbft)
M16hexbolts
230-371N·m(170-274lbft)
