Case 2050M Tier2 - Torque Specifications

INTRODUCTION
Torque-Specialtorques
2050M
Ripper
Component
Torque
Rippermountingbolts
1016–1375N·m(749–1014lbft)
Ripperpinretainingandtubecoverbolts
301–407N·m(222–300lbft)
FuseandRelayBlocks
Component
Torque
Fuseblockmounting
6.5N·m(4.8lbft)
PumpsandMotors
Component
Torque
Pumpmountboltstocover
587–690N·m(433–509lbft)
Motormountboltstonaldrives250–280N·m(184–207lbft)
Pumptomotorhosesspitangeclamps90–100Nm(66–74lbft)
Inlethoseclamps
6.5–7.6Nm(58–68lbin)
RearFrameCover
Component
Torque
M24hexbolts
449–725N·m(331–535lbft)
M16hexbolts
230–371N·m(170–274lbft)
Track
Component
Torque
Masterlinkbolts(UseLOCTITE®242®onmasterlink
bolts.)
610–670N·m(450–494lbft)
Standardlinkshoebolts610–670N·m(450–494lbft)
FinalDrives
Component
Torque
DriveHubRollingTorque
10–24N·m(7–18lbft)
InputShaftBearingRetainerPlateMountingBolts77–87N·m(57–64lbft)
ParkBrakeHousingPlate
77–87N·m(57–64lbft)
BrakeHousingCover-M20X5012pnt650–730N·m(479–538lbft)
BrakeLineFitting
55–60N·m(41–44lbft)
BrakeBleederFitting
24–30N·m(18–22lbft)
CounterShaftBearingRetainerPlateMountingBolts135–150N·m(100–111lbft)
SpindleHousing335–375N·m(247–277lbft)
RingGearRetainingPlate335–375N·m(247–277lbft)
SunGearShaftRetainingPlate135–150N·m(100–111lbft)
OutputGearBearingRetainerPlateMountingBolts135–150N·m(100–111lbft)
PlanetaryCarriertoDriveHub335–375N·m(247–277lbft)
FinalDriveHousingtoFrameMountingBolts
656–725N·m(484–535lbft)
FillCheckPlug24–30N·m(18–22lbft)
DrainPlug
24–30N·m(18–22lbft)
CabMounting
Component
Torque
Supportmountbolts733–854N·m(541–630lbft)
Brushguardmountbolts(ifequipped)587–794N·m(433–586lbft)
4803732115/02/2017
11
