Engine-Engineandcrankcase
27.Installtheturbooutletaircoolingline(1)withclamps.
Torquetheclampattheendmatingthechargeair
coolerto10.1–11.3N·m(7.4–8.3lbft).Installa
newO-ringattheendmatingtheengineandtorque
theclamp(2)to5.8–7.8N·m(4.3–5.8lbft).
LEIL17WHL0091AB20
28.Connectthebottomenginecoolantline(1)totheen-
ginewiththeclamp(2).Torquetheclampto10.1–
11.3N·m(7.4–8.3lbft).
LEIL17WHL0092AB21
29.Installthetopcoolingline(1)withclamps(2).Torque
theclampsattheendsmatingtheelbowhoseand
engineto10.1–11.3N·m(7.4–8.3lbft).
LEIL17WHL0093AB22
30.Fixthetopcoolinglinetothemufersupportstructure
withU-boltclamp.
LEIL17WHL0095AB23
