56 SECTION 21 - TRANSMISSION
HYDRAULIC DOG CLUTCH 4WD DISASSEMBLY
The hydraulic dog clutch 4WD assembly.
Position the shaft in a soft jawed vice and remove
the sealing ring.
Using the appropriate bearing puller 380002685 re-
move the rear bearing.
Remove the thrust washer.
