64 SECTION 21 - TRANSMISSION
HYDRAULIC MULTI PLATE CLUTCH 4WD SHAFT
DISASSEMBLY
The hydraulic multiplate clutch 4WD shaft assembly.
Mount the shaft assembly in a suitable soft jawed
vice and remove the rear sealing ring.
Using the appropriate bearing puller 380002685 re-
move the rear bearing.
Remove the thrust washer and the thrust bearing.
