14 SECTION 02 - TECHNICAL SPECIFICATIONS
TYRES FRONT REAR
2WD 11L-16F 18.4-26
4WD 12.5/80-18 18.4-26
Dimensions 2WD with standard bucket 4WD with standard bucket
A 4130 mm 4250 mm
B 3345 mm 3460 mm
C 2550 mm 2685 mm
D 45° 45°
E 45° 45°
F 875 mm 830 mm
G 2950 mm 2950 mm
H 240 mm 120 mm
I 2060 mm 1973 mm
J 2175 mm 2175 mm
K 1325 mm 1325 mm
L 1630 mm 1630 mm
M 5865 mm 5778 mm
N 4000 mm 4000 mm
P 2430 mm 2430 mm
Q 2250 mm 2250 mm
Performance 2WD 4WD
Lifting capacity at
maximum height
3325 kg 3450 kg
Breakout force 6556 daN 6537 daN
LOADER BUCKETS
Type Normal operation 4x1 6x1 (with forks)
Heaped capacity
1.00 m
3
1.00 m
3
1.00 m
3
Width 2250 mm 2250 mm 2250 mm
Weight 410 kg 800 kg 960 kg
