Case 580SR - Page 407

SECTION 25 - FRONT AXLES 55
Assemble the seal ring (5).
SWARNING
Positioning the seal ring (5) as in figure.
Insert the cardan shaft (6) into the axle shaft (1).
SWARNING
Be careful not to damage the seal ring.
F27278
5
6
1
F27273
