SECTION 25 - FRONT AXLES 61
Once all the adjustment operations have been com-
pleted, fit the ring nut retainers (8) and their screws
(9), tightening them to the requested torque.
Tighten the bolts (12) of both half collars (11) to the
requested torque.
Before matching surfaces, make sure that they are
perfectly clean, degrease and clean them with ap-
propriate detergents.
Spread a film of adhesive on the contact surface be-
tween the axle beam (14) and the differential carrier.
NOTE: check that the two pins (13) are in their
housing.
Position the differential support (1) on the axle hous-
ing (14), and tighten the retaining screws (2) to the
requested torque.
F27298
9
8
F27299
12
13
F27300
13
13
14
F27301
14
2
1
